OSHA requirements for a small machine tool shop

Last updated 2026-07-11

Which OSHA standards actually apply to a machine tool shop?

A fixed machine shop lives under OSHA's General Industry standards, 29 CFR Part 1910, not the construction standards. If your crew does on-site installation or erection work, some Part 1926 rules may also reach you. For everything happening on your shop floor, Part 1910 is the rulebook.

The standards that surface most in machine shop inspections are ^[1]:

• 29 CFR 1910.147 (lockout/tagout)
• 29 CFR 1910.212 (machine guarding)
• 29 CFR 1910.132 to 138 (personal protective equipment)
• 29 CFR 1910.1200 (hazard communication / SDS)
• 29 CFR 1910.95 (occupational noise exposure)
• 29 CFR 1910.217 (mechanical power presses, if applicable)
• 29 CFR 1910.303 to 308 (electrical wiring and safety)
• 29 CFR 1910.157 (portable fire extinguishers)
• 29 CFR 1910.1000 (air contaminants / permissible exposure limits)
• 29 CFR Part 1904 (recordkeeping)

That list looks long. It is. But most of these standards share one skeleton: find the hazard, control it, write down what you did, train your people. Do that work once and a good chunk of it carries over to the next standard.

Here's the part that catches small shops flat. OSHA's General Duty Clause (Section 5(a)(1) of the OSH Act) lets an inspector cite you for any recognized hazard even when no specific standard names it ^[2]. "There's no rule for this exact thing" is not a defense when the danger is obvious.

What are the lockout/tagout requirements for machine shops?

Lockout/tagout (LOTO) under 29 CFR 1910.147 is the most-cited standard in manufacturing, and machine shops are no exception ^[1]. The rule makes you control hazardous energy before anyone services, maintains, or clears a jam on a machine. A padlock alone does not satisfy it.

Here's what the standard puts in writing ^[3]:

1. An energy control program (a written document) 2. Machine-specific energy control procedures for each piece of equipment that can release stored energy 3. An annual inspection of each procedure, documented with the date, equipment, employees involved, and the name of the person doing the review 4. Training for authorized employees (those who lock out) and affected employees (those who work in the area)

The written program and machine-specific procedures are where most small shops come up short. Each lathe, mill, grinder, and press needs its own procedure naming every energy source (electrical, hydraulic, pneumatic, gravitational, thermal) and the steps to isolate and verify each one.

For a deeper look at building these procedures, see our guide to lockout tagout.

Serious LOTO violations run $1,000 to $16,131 each as of 2024, and a willful violation can reach $161,323 ^[4]. The math on getting this right is not hard.

What machine guarding does OSHA require?

29 CFR 1910.212 is the main machine guarding standard, and it's written broadly on purpose. The standard says "one or more methods of machine guarding shall be provided to protect the operator and other employees in the machine area from hazards such as those created by point of operation, ingoing nip points, rotating parts, flying chips and sparks" ^[5].

That language stays general because machines vary so much. Specific machines get their own supplemental standards:

Machine type	Primary guarding standard
Abrasive wheels / grinders	29 CFR 1910.215
Mechanical power presses	29 CFR 1910.217
Woodworking machinery	29 CFR 1910.213
Sawing machines	29 CFR 1910.213
General machinery	29 CFR 1910.212

A typical CNC or manual shop deals mostly with 1910.212 and 1910.215. The practical points:

• Guards must be firmly secured and not easy for an operator to pull off. Duct tape is a citation.
• Point-of-operation guards must keep hands out of the danger zone during the machine cycle.
• Barrier guards, two-hand tripping devices, electronic safety devices, and restraints all qualify if they give equivalent protection.
• Grinder wheel speeds must match the wheel's rated RPM, and the guard must cover at least 270 degrees of the wheel.

One mistake shows up again and again: pulling a guard to speed up setup or loading, then "planning to put it back." OSHA doesn't grade on intent.

What PPE do machine shop employees need?

29 CFR 1910.132 makes you assess the workplace for hazards, decide what PPE fits, and write that assessment down. The document doesn't have to be fancy. It does have to be written and signed ^[6].

For a typical machine shop, the assessment almost always lands on:

• Safety glasses with side shields (or face shields for grinding and heavy chip work) under 1910.133
• Steel-toed or composite-toed footwear when heavy workpieces or tooling get handled (usually driven by the assessment, not a named mandate)
• Hearing protection once noise crosses 85 dB(A) as an 8-hour TWA, under 1910.95
• Cut-resistant gloves for raw stock and sharp parts, with one big caveat: no gloves near rotating spindles
• Chemical-resistant gloves and goggles for cutting fluids, coolants, or solvents

The glove rule near rotating equipment earns its own paragraph. Gloves stay off while running lathes, mills, drills, or grinders, because a spinning tool can catch a glove and pull a hand in faster than anyone can pull back. Your PPE assessment needs to name that control directly.

The employer pays for most required PPE under 1910.132(h). Prescription safety glasses, ordinary footwear worn off the job, and logging boots sit in the narrow list of exceptions ^[6].

What does the hazard communication standard require for a machine shop?

29 CFR 1910.1200, the Hazard Communication Standard (HazCom), covers any workplace where employees can be exposed to hazardous chemicals ^[7]. Machine shops have plenty: cutting oils, coolants, lubricants, cleaning solvents, welding fumes if there's welding, and metalworking fluids that grow bacteria and cause lung disease over time.

The standard has five moving parts:

1. A written hazard communication program 2. A chemical inventory list 3. Safety Data Sheets (SDS) for every hazardous chemical on site, reachable during every shift 4. Labels on all containers 5. Training for every employee who might be exposed

The SDS piece trips up a lot of shops. You need a sheet for every product that qualifies, more than the obviously nasty ones. Cutting fluids, rust inhibitors, even some aerosol lubricants make the list. A supplier who won't hand over an SDS is a warning sign.

Metalworking fluids deserve their own attention. NIOSH ties metalworking fluid exposure to respiratory disease and cancer and recommends a thoracic-fraction limit of 0.4 mg/m3, well below OSHA's older mist limit ^[8]. If coolant or cutting fluid runs anywhere in your shop, your HazCom program has to address it by name.

For more on building the written program, see our hazard communication guide.

What are the OSHA noise requirements for a machine shop?

Machine shops are loud. Lathes, mills, grinders, and air lines routinely push 85 to 100 dB(A) or higher. 29 CFR 1910.95 sets the permissible exposure limits and forces a hearing conservation program once employees hit 85 dB(A) as an 8-hour time-weighted average.

Here's the PEL table that matters ^[9]:

Duration (hours/day)	Permissible sound level (dB(A))
8	90
6	92
4	95
2	100
1	105
0.5	110
0.25 or less	115

The action level, 85 dB(A) TWA, triggers a hearing conservation program: noise monitoring, audiometric testing, hearing protection, training, and recordkeeping. The PEL, 90 dB(A) TWA, is the hard ceiling.

A quick field test: if you can't talk to someone at arm's length without raising your voice, you're probably at or above 85 dB(A). Take a sound level meter reading before you assume you're under the action level. Plenty of shops just issue hearing protection to everyone on the floor and document the call. That isn't the worst move, even though it doesn't replace real monitoring.

Does a small machine shop have to keep OSHA injury records?

Size decides this one. OSHA's recordkeeping rules under 29 CFR Part 1904 make establishments keep an OSHA 300 log, a 300-A summary, and a 301 incident report for each recordable injury or illness ^[10].

There's a partial exemption. Employers with 10 or fewer employees at all times during the previous calendar year skip the routine recordkeeping under 1904.1 ^[10]. That break covers the logs and reports, not the safety standards underneath them. You still report any fatality to OSHA within 8 hours, and any inpatient hospitalization, amputation, or loss of an eye within 24 hours, no matter your headcount ^[10].

If your shop runs 11 or more employees, you keep the OSHA 300 log all year, post the 300-A summary from February 1 through April 30, and hold the records for five years.

Machine shops in metalworking machinery manufacturing (NAICS 333517 and related codes) may also fall under OSHA's electronic reporting rule, which makes them submit 300-A data through OSHA's Injury Tracking Application once they hit 20 or more employees ^[10].

See our guide to writing a solid incident report for the 301 process.

What written safety programs does a machine shop need?

OSHA never publishes one master list of required written programs. The demand to write something down sits inside individual standards. For a machine shop, the programs you'll almost certainly need are:

• Energy Control Program (LOTO), required by 1910.147(c)(1)
• Hazard Communication Program, required by 1910.1200(e)
• Respiratory Protection Program, required by 1910.134(c) if respirators are used (even voluntary use needs a written program)
• Hearing Conservation Program, required by 1910.95(c) if you're at or above the 85 dB(A) action level
• PPE Hazard Assessment, required by 1910.132(d)(2)
• Emergency Action Plan, required by 1910.38 for shops with more than 10 employees or those required to keep fire extinguishers
• Bloodborne Pathogens Exposure Control Plan, required by 1910.1030 if employees may have occupational exposure (uncommon in machine shops, but it matters if anyone provides first aid)

Smaller shops often ask about a full Injury and Illness Prevention Program (IIPP). No federal IIPP rule has been finalized as of mid-2026. But 22 states and territories run their own OSHA-approved State Plans, and several, including California, Washington, and Minnesota, already require an IIPP ^[11].

Building all of these feels like a lot because it is. SafetyFolio's safety program generator walks you through every required written program for your specific shop in about 15 minutes, using your actual equipment and headcount.

What OSHA training do machine shop employees need?

OSHA doesn't force one training format. It forces training that meets the content and frequency baked into each standard, delivered in a language the employee understands.

For a machine shop, the required training includes:

• LOTO training: authorized and affected employees, before assignment and whenever procedures change (1910.147(c)(7))
• HazCom training: at initial assignment and whenever a new hazardous chemical shows up (1910.1200(h))
• PPE training: before use (1910.132(f))
• Hearing conservation training: annually for employees in the program (1910.95(k))
• Machine-specific training: driven by the General Duty Clause and various machine standards; no set frequency, but retraining after an incident or an observed lapse is smart
• Powered industrial truck (forklift) training: if you have a forklift, 1910.178(l) requires formal instruction, hands-on practice, and evaluation every three years; see our guide to forklift certification

For supervisors and safety leads, a formal OSHA 30 course (30 hours on General Industry standards) gives a good base. It doesn't satisfy any single standard's training requirement by itself, but it hands your frontline supervisors the framework to spot and fix hazards.

Keep training records. No universal retention period is written into the General Industry standards, but a workable rule is length of employment plus five years.

What electrical safety requirements apply to machine shops?

Machine tools run on electricity, often 480V three-phase. OSHA's electrical standards under 29 CFR 1910 Subpart S (1910.301 through 1910.399) and the referenced NFPA 70 (the National Electrical Code) set the floor ^[12].

The practical electrical requirements for a shop:

• Every electrical panel and junction box must be covered. Open knock-outs and missing panel covers are among the most common easy citations.
• Keep at least 36 inches of clearance in front of panels rated 0-150V to ground, or 42 inches for panels over 150V, so emergency shutoff stays reachable (1910.303(g)(1)).
• Extension cords are not permanent wiring. Obvious, and routinely ignored.
• Ground Fault Circuit Interrupters (GFCIs) are required in wet locations and for temporary power.
• Electrical work goes to a qualified person; OSHA's definition of "qualified" under 1910.399 is specific and ties to training and experience at the equipment's voltage.

If your CNC gear uses programmable controllers, the electrical interlocks that stop machine motion during a door-open or tool-change cycle are safety devices, not conveniences. Bypassing one is a General Duty Clause violation at minimum, and a 1910.212 violation if it opens a guarding hazard.

How does OSHA handle air quality and cutting fluid mists in machine shops?

This is where compliance gets genuinely messy. 29 CFR 1910.1000 sets permissible exposure limits for dozens of air contaminants across Tables Z-1, Z-2, and Z-3. Metalworking fluid mists fall under the oil mist PEL of 5 mg/m3 as an 8-hour TWA ^[13].

The catch: many of OSHA's PELs are widely viewed as out of date. NIOSH's recommended exposure limits (RELs) often run lower, and ACGIH threshold limit values (TLVs) lower still. OSHA says so plainly in its own guidance. If your shop runs flood coolant or misting systems, aim for the NIOSH REL for metalworking fluids, 0.4 mg/m3 thoracic fraction, rather than the older 5 mg/m3 PEL ^[8].

Engineering controls come first: enclosures, local exhaust ventilation, and coolant management (regular sump cleaning, biocide use, concentration checks) cut exposure more reliably than respirators. If respirators are still needed after those controls, you need a written respiratory protection program under 1910.134.

Dry machining of certain metals (beryllium, cadmium, lead, hexavalent chromium) drops you into substance-specific standards with their own PELs, medical surveillance, and paperwork. Grinding and welding stainless steel generates hexavalent chromium, covered under 1910.1026. Know which alloys you cut.

What does an OSHA inspection of a machine shop look like?

Inspectors targeting machine shops usually start with a walk of the floor before they ask for a single document. They watch machines as they actually run, not as they're supposed to run.

Common citations from manufacturing inspections, in rough order of frequency ^[1]:

1. Lockout/tagout (1910.147): missing written program, missing machine-specific procedures, thin training records 2. Machine guarding (1910.212 and 1910.215): missing or inadequate guards, especially on grinders and drill presses 3. Hazard communication (1910.1200): missing SDS files, unlabeled secondary containers, no written program 4. General electrical (1910.303): open panels, clearance problems, extension cords as permanent wiring 5. PPE (1910.132 and 1910.133): no written hazard assessment, missing eye protection

After the walk, the inspector asks for your written programs, training records, injury logs (if you keep them), and equipment maintenance records. Having those in one place changes how the whole visit goes. Missing or scrambled records are often citable on their own.

OSHA almost always arrives without notice. You can ask to see credentials and request a short delay so management can be present. You cannot refuse entry. Expect an opening conference, the walk-around, and a closing conference where the inspector lays out preliminary findings.

What are the fire safety and housekeeping requirements for a machine shop?

Fire safety in a machine shop runs mostly through 29 CFR 1910.157 (portable fire extinguishers), 1910.106 (flammable liquids), and 1910.38 (emergency action plans). Housekeeping lives under 1910.22.

The key requirements:

• Portable fire extinguishers get a monthly visual check and an annual maintenance service by a certified provider. Keep a written inspection record.
• Flammable and combustible liquids (some cutting oils and solvents included) go in approved containers, and in flammable storage cabinets once quantities cross the thresholds in 1910.106.
• Oily rags are a real fire hazard. Store them in metal containers with self-closing lids.
• Aisle widths must hold (at least 28 inches under 1910.22, and many fire codes want more). Material or equipment stacked in an aisle is both an egress violation and a trip hazard.
• Emergency exits stay marked, unobstructed, and functional. Exit signs stay illuminated.

1910.22 also requires clean, dry floors, drainage where wet processes run, and passageways clear of hazards. In a machine shop that means chip buildup on the floor is a compliance problem, not a tidiness one. Coolant pooling around a machine is a slip hazard and an air quality problem at once.

Frequently asked questions

Does OSHA require a written safety program for a machine shop with fewer than 10 employees?

Yes, with a caveat. Shops with 10 or fewer employees skip OSHA's injury-log recordkeeping, but they still comply with every applicable safety standard. That includes written programs required by specific rules: the energy control program (1910.147), the hazard communication program (1910.1200), and the PPE hazard assessment (1910.132) are all required no matter the headcount.

How often does OSHA require lockout/tagout retraining?

29 CFR 1910.147(c)(7)(iii) requires retraining when there's reason to believe an employee doesn't understand or follow the energy control procedures. The annual procedure inspection can trigger it, but the standard sets no fixed annual retraining requirement for employees who stay proficient. Most practitioners retrain annually anyway and document it as good practice.

Can machine shop employees use the same lock for lockout on multiple machines?

Each authorized employee needs their own lock that only they can remove, per 1910.147(c)(5)(iii). One employee can use that personal lock across multiple machines in sequence (not at the same time), as long as each machine is properly isolated before work starts. Group lockout with a hasp lets several employees each apply a personal lock to one isolation point.

What noise level triggers an OSHA hearing conservation program in a machine shop?

The action level is 85 dB(A) as an 8-hour time-weighted average, under 29 CFR 1910.95(c). At or above that, you need noise monitoring, annual audiograms, hearing protection, employee training, and recordkeeping. The permissible exposure limit is 90 dB(A) TWA. Most shops with grinding or turning exceed 85 dB(A), which makes a hearing conservation program a near certainty.

Does OSHA require machine operators to wear steel-toed boots?

OSHA's PPE standard (1910.132) requires you to assess the hazard and provide appropriate protection, but it doesn't name steel-toed boots. If your assessment finds a real risk of foot injury from falling workpieces or tooling (and in most machine shops it does), protective footwear becomes required. ASTM F2412 and F2413 spell out the performance criteria.

What SDS documents does a machine shop need to keep on file?

You need a Safety Data Sheet for every hazardous chemical present, including cutting fluids, coolants, rust inhibitors, cleaning solvents, lubricants, and welding materials. SDSs must be in the GHS 16-section format and immediately reachable by employees during their shift, per 1910.1200(g). Electronic SDS systems are fine as long as employees can get to them without a barrier.

What are the OSHA rules for grinder wheel guards in a machine shop?

29 CFR 1910.215 governs abrasive wheel machinery. Guards must cover at least 270 degrees of the wheel. The work rest sits within 1/8 inch of the wheel. The adjustable tongue guard (spark deflector) stays within 1/4 inch of the wheel. Wheels never exceed their marked RPM and get a ring test before mounting. These are among the most cited violations in shops with bench grinders.

Does a machine shop need an emergency action plan?

Yes, under 29 CFR 1910.38, if OSHA requires a fire extinguisher in the facility (it does for most shops) or if the facility has more than 10 employees. The plan covers evacuation routes, assembly points, procedures for employees who stay to run critical equipment, headcount methods, and emergency contacts. Shops with 10 or fewer employees can deliver the plan orally instead of in writing.

How quickly does OSHA need to be notified of a serious injury at a machine shop?

Fatalities go to OSHA within 8 hours of the employer learning of the death. Inpatient hospitalizations, amputations (partial ones included), and loss of an eye go within 24 hours. These reporting rules apply to every employer, regardless of size, under 29 CFR 1904.39. Failing to report carries penalties separate from the underlying incident.

Are CNC machines exempt from OSHA machine guarding requirements?

No. CNC machines fall fully under 29 CFR 1910.212. The door interlocks and enclosures standard on many machining centers do satisfy guarding requirements when they work and aren't bypassed. Disable, defeat, or remove those features and you have a 1910.212 violation regardless of the program. Service and setup modes that expose moving parts require LOTO procedures under 1910.147.

What OSHA training is required for new machine shop employees before they start working?

At minimum, before running equipment or handling chemicals: hazard communication training (1910.1200), PPE training (1910.132), and lockout/tagout training for authorized employees (1910.147). Machine-specific operation training comes before independent operation, though the standard doesn't dictate classroom versus on-the-job. Document every session with the date, content, trainer name, and employee signature.

What OSHA standards cover forklift use inside a machine shop?

29 CFR 1910.178 covers powered industrial trucks. Operators train and get evaluated before operating, with refresher training every three years or after unsafe operation is observed. The forklift gets a pre-shift inspection. Aisle widths, load capacity markings, and pedestrian separation controls apply too. Our guide to forklift certification covers the training requirements in detail.

Can a machine shop owner use OSHA's free consultation service to check compliance?

Yes, and it's genuinely useful. OSHA's free On-Site Consultation Program, separate from enforcement, sends safety professionals to small businesses to find hazards and help build corrective plans, with no citations issued. Take part and fix the hazards in good faith and the business can qualify for OSHA's Safety and Health Achievement Recognition Program (SHARP), which brings a temporary exemption from programmed inspections.
